Chamber Heater for P2S: M2 Install and Air Purifier Guide

In 3D printing, the smell and fumes from melted filament can be a real headache, especially when you start printing higher-temperature materials like ABS or ASA. At the same time, a stable chamber temperature is one of the key conditions for getting cleaner results on materials that shrink, curl, or split when the environment is not steady.

This guide keeps the focus on one practical upgrade for the Bambu Lab P2S: installing the MartilloTech M2 chamber heater and air purifier. The unit is designed as a chamber heater for P2S, with heating, air circulation, filtration, and automatic start/stop behavior. The goal is simple: make the P2S printing environment more stable and more comfortable to run.

Before getting into the steps, here is the realistic expectation. A chamber heater for P2S can help with chamber stability and odor management, but the final result still depends on filament, print settings, room conditions, installation quality, and the exact printer setup.

Before you start, lower the heated bed to the bottom and disconnect the printer from power. This is not the kind of install I would rush, because you will be opening the rear side of the machine and working around wiring.

The back panel has quite a few screws, roughly twenty to thirty in the original install process. I strongly recommend preparing a small screw box or a printed screw organizer first. Keeping screws grouped by location makes reassembly much less painful.

During disassembly, pay attention to a few details. Remove the fixing screw on the upper-left side of the machine case. The pneumatic fitting on the upper-right side may need a bit of careful handling. If you are working on the P2S standalone version, be careful with the silicone plug area because wiring may sit underneath it. Do not pull hard.

One important reminder: the four screws on the left and right sides that are used for belt tension do not need to be removed. In my experience, touching unnecessary adjustment screws is one of the easiest ways to create a second problem while trying to install an upgrade.

This is the core part of the installation, and the order matters. The most useful rule is: route the cable first, then fix the purifier/heater in place. Before mounting the M2 unit to the side panel, pass the power cable out through the rear gap of the printer.

If you fix the chamber heater first, the remaining space becomes tight and cable routing gets much harder. It is a small detail, but it can decide whether the install feels smooth or frustrating.

The kit includes silicone vibration gaskets. Install them with the larger patterned end facing inward and the smaller ring toward the bottom of the screw. This helps the unit sit properly and reduces direct vibration transfer from the printer body.

For power wiring, remove the waste chute section and the lower power protection cover. In the source install notes, the waste chute uses four screws and the lower protection cover uses five screws. After opening the wiring cover, connect the wires by matching colors: orange to orange, brown to brown, and blue to blue. Double-check the wire color match and screw tightness before closing the cover.

After wiring, reinstall the power cover, waste chute, and rear panel in the original order. If you are not comfortable working near printer power wiring, it is better to ask someone experienced to help rather than forcing the install.

If you want to confirm voltage options, package contents, and compatibility before purchase, check the MartilloTech M2 product page here:

After the hardware is installed, do not forget the filtration core. Before using the purifier function, fill the filter box with the included activated carbon pellets. This step is easy to overlook, but it is part of what makes the air purifier function useful.

For ABS, ASA, and similar materials, smell and airborne byproducts are part of the printing experience. A chamber heater for P2S with filtration does not replace good room ventilation, and I would not make exaggerated health claims. But in day-to-day use, combining chamber heating with activated carbon filtration is more practical than only heating the enclosure and ignoring the air comfort side.

The product page also lists H13 HEPA plus activated carbon filtration. Actual performance can vary with filament, room size, filter condition, print duration, and airflow, so treat filtration as a helpful layer, not a total guarantee.

The M2 chamber heater and purifier supports both manual and automatic operation. The panel is straightforward once you know what each control does.

The power switch is on the right side and controls the main power of the unit. The left button switches between cold-air and hot-air modes. When the red light is on, the unit is in hot-air mode, which is used to raise chamber temperature for materials such as ABS. When the blue light is on, the unit is in cold-air mode for air purification only.

The blue knob controls temperature adjustment. The source material describes a 40–60°C stepless adjustment range, which matches the product positioning as a chamber heating upgrade for engineering-material printing.

For normal use, the original install notes strongly recommend A mode, or automatic mode. In this mode, the purifier/heater follows the printer’s working state and starts or stops automatically, reducing the need for manual intervention. The product page describes this as IR auto on/off, with no Wi-Fi or app required.

In my experience, automatic mode is the better default for most users because it makes the upgrade easier to live with. A chamber heater for P2S is only useful if the workflow stays simple enough that you actually use it correctly.

After installing the M2 chamber heater and purifier, the Bambu Lab P2S gains two practical improvements: better chamber-temperature support and better odor-management support. For large prints or higher-shrinkage materials, the stable chamber environment can help reduce the problems that usually show up as warping, corner lifting, or layer splitting.

The important word is help. Material type, slicer settings, bed adhesion, part geometry, room temperature, firmware behavior, and installation details can all affect the result. A chamber heater for P2S is not a guaranteed fix for every failed ABS or ASA print, but it does address one of the major causes: an unstable enclosure environment.

For users who already print engineering materials on the P2S, this upgrade makes the machine feel more prepared for that job. For PLA-only users, it may be less urgent. The value is clearest when you are printing ABS, ASA, Nylon, or other materials that benefit from a warmer and more stable enclosure.

Installing the M2 chamber heater and purifier on the Bambu Lab P2S is a practical DIY upgrade for users who care about chamber stability and air comfort. The install requires patience, especially around screw management, cable routing, and power wiring, but the overall logic is clear: remove the rear panel carefully, route the cable before fixing the unit, match the wires by color, fill the filter box with activated carbon, and use automatic mode for daily printing.

If your goal is a cleaner and more stable ABS/ASA workflow, a chamber heater for P2S is worth considering. Just keep the expectations realistic and remember that printer model, material, installation method, room conditions, and settings will all influence the final result.
