Star-Shaped PTFE Tube for 1.75mm Filament

Name: Star-Shaped PTFE Tube for 1.75mm Filament
Brand: Call3D
SKU: Clear-Star-PTFE-tube-call3d-1
Price: 7.99 USD
Availability: InStock

Star-Shaped PTFE Tube for 1.75mm Filament

Designed to help reduce feeding resistance when printing with TPU filament.

Lower-Resistance TPU Feeding

This star-shaped PTFE tube uses a star-bore profile designed to help reduce TPU feeding resistance on a straight path. Multiple bends can create more resistance than a standard round PTFE tube.

Switch Filaments, Keep the Tube

Keep the same guide tube when switching from TPU to PLA or other compatible, non-carbon-fiber 1.75mm filaments, whether changing spools manually or using a filament track switch. No tube replacement is needed for these material changes.

$7.99

Shipping calculated at checkout.

3 in stock

This star-shaped PTFE tube is designed to help reduce feeding resistance for 1.75mm filament, especially TPU, in a straight guide path. It can also guide PLA and other compatible non-carbon-fiber filaments, so you do not need to replace this tube section when changing between supported materials. Avoid bending or kinking the tube: multiple bends can create more resistance than a standard round PTFE tube. Choose graphite-filled semi-transparent black or pure semi-transparent white PTFE, commonly called Teflon. Confirm connector fit and filament clearance before use.

90-Day Warranty
30-Day Return
7-Day Delivery

Place your order today

28 Oct | Estimated delivery shown for your destination.

🚚 More information regarding shipping & delivery

Star-Shaped PTFE Tube for 1.75mm Filament Overview

Better than Standard PTFE Tube

This tube is for a straight TPU feeding path, not a route with several bends. In a straight run, the star-shaped profile is designed to help reduce TPU feeding resistance, though that result is not guaranteed in every setup. If the path bends more than once, a suitable round PTFE tube is the better choice, because bends can make this tube more resistant than a round one. You can keep the same straight section when you switch from TPU to PLA or another compatible non-carbon-fiber 1.75mm filament, but the tube does not change what your printer or filament switcher supports. For carbon-fiber-filled filament, choose a guide tube made for that material instead.

Product Specification

• Product Type: Filament guide tube
• Material: PTFE; graphite-filled black or pure white
• Filament Diameter: 1.75mm (approximately 0.069 in)
• Outer Diameter: 4mm (approximately 0.157 in)
• Inner Profile: Star-shaped
• Supported Materials: TPU, PLA, and other compatible non-carbon-fiber filaments
• Color Options: Semi-transparent black; semi-transparent white
• Length per Unit: 1m (approximately 3.28 ft)

Package Includes

1 × Star-shaped PTFE tube — 1m (approximately 3.28 ft) per unit ordered
Total supplied length: order quantity × 1m. Quantity 1 = 1m; quantity 2 = 2m; quantity 3 = 3m.
Not included: accessories unless explicitly specified in the selected product option.

Requirements & Installation Notes

Use a straight, direct filament path; do not bend or kink the tube. Multiple bends can create more resistance than a standard round PTFE tube.
For TPU, PLA, and other compatible non-carbon-fiber 1.75mm filaments; tube compatibility does not change your AMS or filament switcher’s material restrictions.
Confirm the 4mm outer diameter matches your connectors, check internal filament clearance, and cut the tube to the required length before installation.

Explore Precision Upgrades for Your Bambu Lab

Frequently Asked Questions About Star-Shaped PTFE Tube for 1.75mm Filament

Is this different from a regular 3D printer PTFE tube?

Yes. A regular round PTFE tube has more continuous contact with the filament. This star-shaped 3d printing PTFE tube uses smaller contact points to reduce feeding drag, which can be helpful for TPU, dry box routing, or enclosure setups.

Is this PTFE tube only for TPU?

No. TPU benefits most because it needs lower feeding resistance, but this Ptfe tube 3d printer guide can also be used with PLA and other compatible 1.75mm filaments. For pure PLA or light-colored materials, the semi-transparent white pure PTFE version is the cleaner option because it avoids possible graphite residue from long-term wear.

How much tubing will I receive?

The tube is sold in 1m units (approximately 3.28 ft per unit). Your order quantity determines the total length supplied: quantity 1 = 1m, quantity 2 = 2m, and quantity 3 = 3m. Choose the quantity according to the total length you need.

Does this tube make TPU compatible with my AMS or filament switcher?

No. A guide tube does not change the materials supported by your AMS or filament switcher. Confirm that your specific device supports the TPU you plan to use, and check the connector fit and filament path. Do not assume all AMS models or switchers can handle ordinary TPU simply because this tube is installed. Keep the tube straight; a device route that requires multiple bends may not suit this tube.
